E3C246D4U / E3C242D4U / C246M WS
10 11
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)
3 ATX Power Connector (ATXPWR1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)
5 Front Fan Connector (FRNT_FAN1)
6 CPU Fan Connector (CPU_FAN1)
7 Front Fan Connector (FRNT_FAN2)
8 SATA SGPIO Connector (SATA_SGPIO1)
9 SATA3 DOM Connector (SATA_0), Red
10 SATA3 Connector (SATA_1)
11 SATA SGPIO Connector (SATA_SGPIO2)
12 USB 3.0 Header (USB3_1_2)
13 SATA DOM Power Jumper (SATAPWR1)
14 SATA DOM Power Header (SATA_PWR1)
15 SATA3 Connector (SATA_2)
16 SATA3 Connector (SATA_3)
17 SATA3 Connector (SATA_4)
18 SATA3 Connector (SATA_5)
19 SATA3 Connector (SATA_6)
(for E3C246D4U / C246M WS only)
20 SATA3 Connector (SATA_7)
(for E3C246D4U / C246M WS only)
21 System Panel Header (PANEL1)
22 Speaker Header (SPEAKER1)
23 Auxiliary Panel Header (AUX_PANEL1)
24 Security Override Jumper (SEC_OR1)
25 Front Fan Connector (FRNT_FAN3)
26 USB 2.0 Header (USB_1_2)
27 TPM Header (TPM1)
28 PCI Express Graphics Conguration Jumper (PEG_CFG1)
29 ermal Sensor Header (TR1)
30 Front Panel Audio Header (HD_AUDIO1)
31 M.2 Socket (M2_1) (Type 2230/2242/2260/2280)*
32 Rear Fan Connector (REAR_FAN2)
33 Rear Fan Connector (REAR_FAN1)
34 Non Maskable Interrupt Button (NMI_BTN1)
*e M.2 slot (M2_1) is shared with the SATA_0 connector. When M2_1 is populated with a M.2 SATA3/
PCIE3.0(x4 or x2) module, SATA_0 is disabled.
