1.6 I/O Panel
E3C242D4U / E3C246D4U
6
4
3
2
1
5
8
7
No. Description No. Description
1 VGA Port (VGA1) 5 LAN RJ-45 Port (LAN1)**
2 Serial Port (COM1) 6
USB 3.1 Ports (USB31_3_4)
E3C242D4U: Gen1
E3C246D4U: Gen2
3 LAN RJ-45 Port (IPMI_LAN)* 7 LAN RJ-45 Port (LAN2)**
4
USB 3.1 Ports (USB31_1_2)
E3C242D4U: Gen2
E3C246D4U: Gen2
8 UID Switch (UID1)
Note: LAN1 supports NCSI.
C246M WS
7
5
3
2
1
6
9
8
10
11
12
4
No. Description No. Description
1 VGA Port (VGA1) 7 USB 3.1 Gen2 Ports (USB31_3_4)
2 Serial Port (COM1) 8 LAN RJ-45 Port (LAN2)**
3 HDMI Port 9 Optical SPDIF Out Port (SPDIF1)
4 DisplayPort 10 Microphone (Pink)***
5 USB 3.1 Gen2 Ports (USB31_1_2) 11 Front Speaker (Lime)***
6 LAN RJ-45 Port (LAN1)** 12 Line In (Light Blue)***
Note: LAN1 supports NCSI.
