![ASRock E3C246D4U [19/87] E3c246d4u e3c242d4u c246m ws](/views2/1694725/page19/bg13.png)
E3C246D4U / E3C242D4U / C246M WS
12 13
English
No. Item Status Description
1 BMC_LED1 Green BMC heartbeat LED
2 SB_PWR1 Green STB PWR ready
3 FRNT_FAN1_LED1 Amber FRNT_FAN1 failed
4 CPU_FAN1_LED1 Amber CPU_FAN1 failed
5 FRNT_FAN2 _LED2 Amber FRNT_FAN2 failed
6 FRNT_FAN3_LED3 Amber FRNT_FAN3 failed
7 REAR _FAN2_LED2 Amber REAR_FAN2 failed
8 REAR _FAN1_LED1 Amber REAR_FAN1 failed
