E3C246D4U / E3C242D4U / C246M WS
2 3
English
Ethernet
Interface 1000 /100 /10 Mbps
LAN E3C246D4U / E3C242D4U:
- 2 x RJ45 GLAN by Intel® i210
- 1 x RJ45 Dedicated IPMI LAN port
C246M WS:
- 2 x RJ45 GLAN by Intel® i210 + Intel® i219
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller E3C246D4U / E3C242D4U:
ASPEED AST2500
C246M WS:
Intel vPro
IPMI Dedicated
GLAN
E3C246D4U / E3C242D4U:
1 x Realtek RTL8211E for dedicated management GLAN
C246M WS:
N/A
Features - Watch Dog
- NMI
Graphics
Controller E3C246D4U / E3C242D4U:
ASPEED AST2500
C246M WS:
CPU pGFX
VRAM E3C246D4U / E3C242D4U:
DDR4 16MB
C246M WS:
N/A
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.1 Port E3C242D4U: 2 (Gen2), 2(Gen1)
E3C246D4U / C246M WS: 4 (Gen2)
LAN Port E3C246D4U / E3C242D4U:
- 2 x RJ45 Gigabit Ethernet LAN ports
- 1 x RJ45 Dedicated IPMI LAN port
C246M WS:
- 2 x RJ45 Gigabit Ethernet LAN ports
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
