ASRock E3C246D4U [78/87] Addon rom display
![ASRock E3C246D4U [78/87] Addon rom display](/views2/1694725/page78/bg4e.png)
72 73
English
AddOn ROM Display
Use this option to adjust AddOn ROM Display. If you enable the option “Full Screen Logo”
but you want to see the AddOn ROM information when the system boots, please select
[Enabled]. Conguration options: [Enabled] and [Disabled]. e default value is [Enabled].
