1.2 Specications
E3C246D4U / E3C242D4U / C246M WS
MB Physical Status
Form Factor mATX
Dimension 9.6'' x 9.6'' (24.4 cm x24.4 cm)
Processor System
CPU Supports Intel® Xeon® E-2100 Processors
Chipset E3C246D4U / C246M WS:
Intel® C246
E3C242D4U
Intel® C242
System Memory
Capacity - 4 x 288-pin DDR4 DIMM slots
- Support up to 64GB DDR4 ECC/non-ECC UDIMM
Type - Dual Channel DDR4 memory technology
- Supports DDR4 ECC/non-ECC UDIMM (client O.S only)
DIMM Size Per
DIMM
ECC and non-EDD UDIMM : 16GB, 8GB, 4GB
DIMM
Frequency
- Non-ECC UDIMM: 2666/2400/2133 MHz
- ECC UDIMM: 2666/2400/2133 MHz
Expansion Slot
PCIe 3.0 x16 Slot 6: Gen3 x16 link, auto switch to x8 link if Slot 4 is
occupied
PCIe 3.0 x8 Slot 4: Gen3 x8 link
PCIe 3.0 x4 Slot 5: Gen3 x4 link
Storage
SATA
Controller
E3C246D4U / C246M WS:
Intel® C246: 8x SATA3 6Gb/s (SATA0-7, SATA0 supports
SATA DOM, and is shared with M.2(PCIE3.0(x4))/ SATA3),
support RAID 0, 1, 5, 10
E3C242D4U:
Intel® C242: 6x SATA3 6Gb/s (SATA0-5, SATA0 supports
SATA DOM, and is shared with M.2(PCIE3.0(x2))/ SATA3),
support RAID 0, 1, 5, 10
Audio
Audio Codec E3C246D4U / E3C242D4U:
N/A
C246M WS:
ALC 892
