Unable to save system setup congurations...
1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it
does not.
2. Conrm whether your power supply provides adaquate and stable power.
Other problems...
1. Try searching keywords related to your problem on ASRock Rack’s FAQ page:
http://www.asrockrack.com/support
