ASRock E3C246D4U [51/87] Advanced screen
![ASRock E3C246D4U [51/87] Advanced screen](/views2/1694725/page51/bg33.png)
E3C246D4U / E3C242D4U / C246M WS
44 45
English
Setting wrong values in this section may cause the system to malfunction.
3.3 Advanced Screen
In this section, you may set the congurations for the following items: CPU Conguration,
DRAM Conguration, Chipset Conguration, Storage Conguration, NVMe Congura-
tion, ACPI Conguration, USB Conguration, Super IO Conguration, Serial Port Con-
sole Redirection, H/W Monitor, Intel SPS Conguration and Instant Flash.
