EPC612D8 Series

4 5

English

is motherboard supports Wake from on Board LAN. To use this function, please make

sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager

> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is

enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard

LAN1&2 can wake up S5 under OS.

If you install Intel® LAN utility, Marvell SATA utility or Realtek HD audio driver, this

motherboard may fail Windows® Hardware Quality Lab (WHQL) certication tests. If you

install the drivers only, it will pass the WHQL tests.

1. About the setting of “Hyper reading Technology”, please check page 55.

2. Due to Intel® CPU spec denition, please install the memory modules on DDR4_A1,

DDR4_B1, DDR4_C1 and DDR4_D1 for the rst priority. If above four DDR4 DIMM

slots are fully installed, and you want to use more than four memory modules, please

install the other memory modules from le to right (from DDR4_A2, DDR4_B2, DDR4_

D2 to DDR4_C2.)

3. Before you implement Quad Channel Memory Technology, make sure to read the instal-

lation guide of memory modules on page 25 for proper installation.
