2.6 Expansion Slots (PCI and PCI Express Slots)

ere are 5 PCI Express slots on this motherboard.

PCIE slot:

PCIE6 (PCIE 3.0 x8 slot, from CPU) is used for PCI Express x8 lane width cards.

PCIE1 and PCIE5 (PCIE 3.0 x16 slot, from CPU) are used for PCI Express x8 lane width

cards.

PCIE3 and PCIE7 (PCIE 3.0 x16 slot, from CPU) are used for PCI Express x16 lane width

cards.

Slot Generation Mechanical Electrical Source

PCIE 7 3.0 x16 x16 CPU

PCIE 6 3.0 x8 x8 CPU

PCIE 5 3.0 x16 x8 CPU

PCIE 3 3.0 x16 x16 CPU

PCIE 1 3.0 x16 x8 CPU

*e M.2 slot shares lanes with PCIe Slot 6 . When Slot 4 PCIe M.2 is populated, Slot 4 runs at x4.

PCI Express Slot Conguration

No. PCIE 7 PCIE 3

Single PCIE Card x16 x0

Two PCIE Cards x8 x8
