AddOn ROM Display
Use this option to adjust AddOn ROM Display. If you enable the option “Full Screen Logo”
but you want to see the AddOn ROM information when the system boots, please select
[Enabled]. Conguration options: [Enabled] and [Disabled]. e default value is [Enabled].
Boot Failure Guard
If the computer fails to boot for a number of times the system automatically restores the
default settings.
Boot Failure Guard Count
Configure the number of attempts to boot until the system automatically restores the
default settings.
