24 25
English
2.4 Installing the CPU Fan and Heatsink
CPU_FAN
1 2
CPU fan for narrow ILM socket
*Support an active or passive heatsink
Before you installed the heatsink, you need to spray thermal interface material between the
CPU and the heatsink to improve heat dissipation.
