English
1.2 Specications
EPC612D8A / EPC612D8A-TB / EPC612D8
MB Physical Status
Form Factor ATX
Dimension 12'' x 9.6'' (30.5 cm x 24.4 cm)
Processor System
CPU Intel® Xeon® processor E5-1600/2600 v3/v4* series
*BIOS version 2.0 or above is required.
Socket Single Socket LGA 2011 R3
Chipset Intel® C612
System Memory
Capacity 8 DIMM slots
Type - Quad Channel memory technology
(see Caution 3)
- Supports DDR4 2400*/2133/1866/1600 RDIMM and
LRDIMM
*Only E5-2600 V4 CPUs support DDR4 2400.
Voltage 1.2V
DIMM Sizes RDIMM: 32GB, 16GB, 8GB, 4GB
LRDIMM: 64GB, 32GB
Expansion Slot
(Slot 7 is the closest to the CPU)
Slot 7 ME x16, EE x16 (x16/x0 or x8/x8 with slot 5)
Slot 6 ME x8, EE x8 (x8 if slot 4 mini PCIe is disabled)
Slot 5 ME x16, EE x8
Slot 4 mini PCIe x4 to support M.2 (Full and Half size support)
*e M.2 slot shares lanes with PCIe Slot 6.
Slot 3 ME x16, EE x16 (x16/x0 or x8/x8 with slot 1)
Slot 2 N/A
Slot 1 ME x16, EE x8
Storage
SATA Controller Intel® C612 : 6 x SATA3 6.0Gb/s; 4 x sSATA3 6.0Gb/s; support
RAID 0, 1, 5, 10 ( 1 x SATA DOM)
Additional SATA
Controller
Marvell 9172: 2 x SATA3 6Gbps
Ethernet
Interface 1000 /100 /10 Mbps
LAN Controller 2 x RJ45 by Intel® i210 + Intel® i217
1 x RJ45 Dedicated IPMI LAN port
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports PXE
