SiUS39-602 Field Setting
Test Operation 91
3.2 Field Setting from Outdoor Unit
3.2.1 Field Setting from Outdoor Unit
Setting by dip switches
The following field settings are made by dip switches on PC board.
Dipswitch
Setting item Description
No. Setting
DS1-1
ON
Not used Do not change the factory settings.
OFF (Factory set)
DS1-2
~DS1-4
ON
Not used Do not change the factory settings.
OFF (Factory set)
DS2-1
~4
ON
Not used Do not change the factory settings.
OFF (Factory set)
DS3-1,
2
ON
Not used Do not change the factory settings.
OFF (Factory set)
Caution
DIP switch Setting after changing the main P.C.Board(A1P) to spare parts P.C.B.
When you change the main P.C.Board(A1P) to spare parts P.C.B., please carry out the following
setting.
DIP Switch Detail
DS No. Item Contents
DS1-1
——
DS1-2 Power supply
setting
ON 3 phase 200 Volt area
OFF 3 phase 400 Volt area
DS1-3
——
DS1-4 Refrigerant
classification
(Do not set)
DS2-1
DS2-2 Capacity setting
DS2-3
DS2-4
1 2 3 4 1 2 3 4
DS1 DS2
ON
OFF
ON
OFF
R-410A
DS1-4 OFF
DS2-1 ON
72, 96
DS2-2 OFF
DS2-3 OFF
DS2-4 ON
