Specifications SiUS39-602
12 Specifications
Ceiling Mounted Cassette Type (Multi-flow)
Notes:
★
1 Nominal cooling capacities are based on the following conditions:
Return air temperature: 80°FDB, 67°FWB
Outdoor temperature: 95°FDB
Equivalent ref. piping length : 25ft (Horizontal)
★
2 Nominal heating capacities are based on the following conditions:
Return air temperature: 70°FDB.
Outdoor temperature: 47°FDB, 43°FWB
Equivalent ref. piping length: 25ft (Horizontal)
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
4 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of installation conditions.
Model FXFQ30MVJU FXFQ36MVJU
★
1 Cooling Capacity Btu/h 30,000 36,000
★
2 Heating Capacity Btu/h 34,000 40,000
Casing / Color Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) in 11-3/8
×
33-1/8
×
33-1/8 11-3/8
×
33-1/8
×
33-1/8
Coil (Cross
Fin Coil)
Rows × Stages × FPI 2
×
12
×
17 2×12×17
Face Area ft² 5.35 5.35
Fan
Model QTS45A17M QTS45A17M
Type Turbo Fan Turbo Fan
Motor Output HP 0.12 0.12
Air Flow Rate (H/L) cfm 990/710 990/740
Drive Direct Drive Direct Drive
Temperature Control Microprocessor Thermostat for Cooling and Heating Microprocessor Thermostat for Cooling and Heating
Sound Absorbing Thermal Insulation Material
Foamed Polystyrene /
Foamed Polyethylene
Foamed Polystyrene /
Foamed Polyethylene
Piping
Connections
Liquid Pipes in
φ
3/8 (Flare Connection)
φ
3/8 (Flare Connection)
Gas Pipes in
φ
5/8 (Flare Connection)
φ
5/8 (Flare Connection)
Drain Pipe in
VP25
External Dia. 1-1/4
Internal Dia. 1
VP25
External Dia. 1-1/4
Internal Dia. 1
Machine Weight (Mass) Lbs 66 66
★
4 Sound Level (H/L) dBA 38/32 40/33
Safety Devices Fuse, Thermal Protector for Fan Motor Fuse, Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-410A Series R-410A Series
Decoration
Panels
(Option)
Model BYC125K-W1 BYC125K-W1
Color White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) in 1-5/8
×
37-3/8
×
37-3/8 1-5/8
×
37-3/8
×
37-3/8
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight Lbs 11 11
Standard Accessories
Operation manual, Installation manual, Paper pattern for
installation, Drain hose, Clamp metal, Washers, Sealing
pads, Clamps, Screws, Insulation for fitting.
Operation manual, Installation manual, Paper pattern for
installation, Drain hose, Clamp metal, Washers, Sealing
pads, Clamps, Screws, Insulation for fitting.
Drawing No. C:3D042686
() ()
