Specifications SiUS39-602
6 Specifications
1. Specifications
1.1 Outdoor Units
Notes:
★
1 Indoor temp. : 80°FDB or 67°FWB / outdoor temp. : 95°FDB / Equivalent piping length : 25 ft, level
difference: 0.
★
2 Indoor temp. : 70°FDB / outdoor temp. : 47°FDB or 43°FWB / Equivalent piping length : 25 ft, level
difference: 0.
★
3 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of ambient conditions.
Model Name REYQ72MTJU
★
1 Cooling Capacity Btu / h 72,000
★
2 Heating Capacity Btu / h 81,000
Casing Color Ivory White (5Y7.5/1)
Dimensions: (H×W×D) in 64 × 48-7/8 × 30-1/8
Heat Exchanger Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 13.72+10.47
Number of Revolutions r.p.m 6480, 2900
Motor Output × Number
of Units
kW (2.7+4.5) × 1
Starting Method Direct on line
Fan
Type Propeller Fan
Motor Output kW 0.75 × 1
Air Flow Rate cfm 7,400
Drive Direct Drive
Connecting
Pipes
Liquid Pipe in 3/8 in C1220T (Flare Connection)
Gas Pipe in 3/4 in C1220T (Brazing Connection)
Discharge Gas Pipe in 5/8 in C1220T (Brazing Connection)
Machine Weight (Mass) Lbs 666
★
3 Sound Level (Reference Value) dBA 60
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over Current Relay, Inverter Overload Protector, Fusible Plugs,
Ground fault circuit interrupter
Defrost Method Deicer
Capacity Control % 14~100
Refrigerant
Refrigerant Name R-410A Series
Charge Lbs 27.3
Control Electronic Expansion Valve
Refrigerator
Oil
Synthetic (ether) oil
Charge Volume L 1.9+1.6
Standard Accessories Installation Manual, Operation Manual, Connection Pipes, Clamps
Drawing No. 4D053303A
