Model Names of Indoor/Outdoor Units SiUS39-602
2 General Information
1. Model Names of Indoor/Outdoor Units
Indoor Units
BS Units
Outdoor Units (Inverter Series)
This time we publish SiUS39-602 (New information: REYQ 72, 144, 168MTJU Wall Mounted
Type FXAQ07, 09M) as shown by .
Type Model Name Power Supply
Ceiling Mounted
Cassette Type
(Multi Flow)
FXFQ — — 12M 18M 24M 30M 36M —
VJU
Slim Ceiling Mounted
Duct Type
FXDQ 07M 09M 12M 18M 24M — — —
Ceiling Mounted
Built-In Type
FXSQ — — 12M 18M 24M 30M 36M 48M
Ceiling Mounted
Duct Type
FXMQ — — — — — 30M 36M 48M
Ceiling Suspended
Type
FXHQ — — 12M — 24M — 36M —
Wall Mounted Type FXAQ 07M 09M 12M 18M 24M — — —
Floor Standing Type FXLQ — — 12M 18M 24M — — —
Concealed Floor
Standing Type
FXNQ — — 12M 18M 24M — — —
Type Model Name Power Supply
Heat Recovery Series
BSVQ 36M 60M VJU
Series Model Name Power Supply
Inverter Heat Recovery REYQ 72M 96M 144M 168M 192M TJU
VJU: 1φ, 208~230V, 60Hz
TJU: 3φ, 208~230V, 60Hz
