List of Electrical and Functional Parts SiUS39-602
230 Appendix
3. List of Electrical and Functional Parts
3.1 Outdoor Unit
3.1.1 REYQ72M, 96MTJU
Item Name Symbol
Model
REYQ72M, 96MTJUY1B
Compressor
Inverter
Type
M1C
JT100FCVDKT
Output 2.7kW
STD.1
Type
M2C
JT170FCKTJ
Output 4.5kW
Crankcase heater (INV) E1HC 33W
Crankcase heater (STD.1) E2HC 33W
Crankcase heater (STD.2) E3HC —
Over current protection device
for STD compressor
— 34A
Fan
motor
Motor M1F 0.75kW
Over current protection device — 10A
Functional
parts
Electronic expansion valve
(Main: EV1)
Y1E Cooling:1400pls Heating:PI control
Electronic expansion valve
(Sub: EV2)
Y2E Cooling:1400pls Heating:PI control
Electronic expansion valve
(Sub-cool: EV3)
Y3E Cooling:PI control Heating:0pls
Solenoid valve (Hot gas: SVP) Y1S VPV-603D
Solenoid valve (External multi
oil: SVO)
Y2S TEV1620DQ2
Solenoid valve (Receiver gas
charge: SVL)
Y3S TEV1620DQ2
Solenoid valve (Receiver gas
discharge: SVG)
Y4S VPV-603D
Solenoid valve (Discharge gas
pipe closing: SVR)
Y5S BPV1706
Solenoid valve (Non-operating
unit liquid pipe closing: SVSL)
Y6S VPV-803DXF
Solenoid valve (High pressure gas
pipe pressure reduction: SVC)
Y7S BPV1706
4-way selector valve (20S1 Main)
Y8S VHV0404
4-way selector valve (20S2 Sub)
Y9S VT3101C
Pressure-
related
parts
Pressure switch (INV) S1PH
PS80 ON : 551+0/-14.5psi OFF : 413±21.8psi
Pressure switch (STD1) S2PH
Fusible plug — FPGD-3D 158 to 167°F
Pressure sensor (HP) S1NPH PS8051A 0 to 601.9psi
Pressure sensor (LP) S1NPL PS8051A -14.5 to 246.6psi
Thermistor
INV
PCB
For fin (T fin) R1T 3.5 to 360k
Ω
Main
PCB
For outdoor air (Ta) R1T 3.5 to 360k
Ω
For suction pipe (Ts) R2T 3.5 to 360k
Ω
For discharge pipe
(INV Tdi)
R31T 3.5 to 400k
Ω
For discharge pipe
(STD1 Tds1)
R32T 3.5 to 400k
Ω
For heat exchanger
(Tb)
R4T 3.5 to 360k
Ω
For sub-cooling heat
exchanger (Tsh)
R5T 3.5 to 360k
Ω
For receiver liquid
pipe (Tl)
R6T 3.5 to 360k
Ω
For oil equalizing pipe
(To)
R7T 3.5 to 360k
Ω
Heat exchanger gas
pipe 1 (Tg1)
R81T 3.5 to 360k
Ω
Heat exchanger gas
pipe 2 (Tg2)
R82T 3.5 to 360k
Ω
Others Fuse (A1P) F1, 2U 250VAC 10A Class B
