Thermistor Resistance / Temperature Characteristics SiUS39-602
240 Appendix
Outdoor Unit
Thermistors for
Discharge Pipe
(R31T, 32T)
T°F T°C k
Ω
T°F T°C k
Ω
T°F T°C k
Ω
32.0 0 640.44 122.0 50 72.32 212.0 100 13.35
33.8 1 609.31 123.8 51 69.64 213.8 101 12.95
35.6 2 579.96 125.6 52 67.06 215.6 102 12.57
37.4 3 552.00 127.4 53 64.60 217.4 103 12.20
39.2 4 525.63 129.2 54 62.24 219.2 104 11.84
41.0 5 500.66 131.0 55 59.97 221.0 105 11.49
42.8 6 477.01 132.8 56 57.80 222.8 106 11.15
44.6 7 454.60 134.6 57 55.72 224.6 107 10.83
46.4 8 433.37 136.4 58 53.72 226.4 108 10.52
48.2 9 413.24 138.2 59 51.98 228.2 109 10.21
50.0 10 394.16 140.0 60 49.96 230.0 110 9.92
51.8 11 376.05 141.8 61 48.19 231.8 111 9.64
53.6 12 358.88 143.6 62 46.49 233.6 112 9.36
55.4 13 342.58 145.4 63 44.86 235.4 113 9.10
57.2 14 327.10 147.2 64 43.30 237.2 114 8.84
59.0 15 312.41 149.0 65 41.79 239.0 115 8.59
60.8 16 298.45 150.8 66 40.35 240.8 116 8.35
62.6 17 285.18 152.6 67 38.96 242.6 117 8.12
64.4 18 272.58 154.4 68 37.63 244.4 118 7.89
66.2 19 260.60 156.2 69 36.34 246.2 119 7.68
68.0 20 249.00 158.0 70 35.11 248.0 120 7.47
69.8 21 238.36 159.8 71 33.92 249.8 121 7.26
71.6 22 228.05 161.6 72 32.78 251.6 122 7.06
73.4 23 218.24 163.4 73 31.69 253.4 123 6.87
75.2 24 208.90 165.2 74 30.63 255.2 124 6.69
77.0 25 200.00 167.0 75 29.61 257.0 125 6.51
78.8 26 191.53 168.8 76 28.64 258.8 126 6.33
80.6 27 183.46 170.6 77 27.69 260.6 127 6.16
82.4 28 175.77 172.4 78 26.79 262.4 128 6.00
84.2 29 168.44 174.2 79 25.91 264.2 129 5.84
86.0 30 161.45 176.0 80 25.07 266.0 130 5.69
86.0 31 154.79 177.8 81 24.26 267.8 131 5.54
87.8 32 148.43 179.6 82 23.48 269.6 132 5.39
89.6 33 142.37 181.4 83 22.73 271.4 133 5.25
91.4 34 136.59 183.2 84 22.01 273.2 134 5.12
93.2 35 131.06 185.0 85 21.31 275.0 135 4.98
95.0 36 125.79 186.8 86 20.63 276.8 136 4.86
96.8 37 120.76 188.6 87 19.98 278.6 137 4.73
98.6 38 115.95 190.4 88 19.36 280.4 138 4.61
100.4 39 111.35 192.2 89 18.75 282.2 139 4.49
102.2 40 106.96 194.0 90 18.17 284.0 140 4.38
104.0 41 102.76 195.8 91 17.61 285.8 141 4.27
105.8 42 98.75 197.6 92 17.07 287.6 142 4.16
107.6 43 94.92 199.4 93 16.54 289.4 143 4.06
109.4 44 91.25 201.2 94 16.04 291.2 144 3.96
111.2 45 87.74 203.0 95 15.55 293.0 145 3.86
113.0 46 84.38 204.8 96 15.08 294.8 146 3.76
114.8 47 81.16 206.6 97 14.62 296.6 147 3.67
116.6 48 78.09 208.4 98 14.18 298.4 148 3.58
118.4 49 75.14 210.2 99 13.76 300.2 149 3.49
120.2 50 72.32 212.0 100 13.35 302.0 150 3.41
