Basic Control SiUS39-602
40 Function
2. Basic Control
2.1 Normal Operation
Cooling Operation
In heating operation, or heating / cooling operation
★
Heating operation is not functional at an outdoor air temperature of 77°F or more.
Actuator Operation Remarks
Compressor Compressor PI control
Used for high pressure control, low pressure
protection control,discharge pipe temperature
protection control, and compressor operating
frequency upper limit control with inverter
protection control.
Outdoor unit fan Cooling fan control
Four way valve 1 (20S1) OFF
Four way valve 2 (20S2) OFF
Main motorized valve (EV1) 1400 pls
Sub motorized valve (EV2) 1400 pls
Sub-cooling motorized valve (EV3) PI control (EV3 control)
Hot gas bypass valve (SVP) Protection control
This valve turns on with low pressure protection
control.
Oil equalization valve (SVO) Oil level equalizing control
In the case of multi-outdoor-unit system, this valve
repeats ON/OFF operation at regular intervals of
time.
Receiver gas charging valve (SVL) OFF
This valve turns on when outdoor temperature is
low.
Receiver gas discharge valve (SVG) ON
Discharge pipe stop valve (SVR) OFF
Non-operating unit liquid pipe stop valve
(SVSL)
OFF
High pressure gas pipe pressure
reduction valve (SVC)
ON
Actuator Operation Remarks
Compressor Compressor PI control
Used for high pressure control, low pressure
protection control,discharge pipe temperature
protection control, and compressor operating
frequency upper limit control with inverter
protection control.
Outdoor unit fan Cooling fan control
Four way valve 1 (20S1)
Depend on heat exchanger
mode (heating, simultaneous
cooling / heating operation)
Four way valve 2 (20S2)
Depend on heat exchanger
mode (heating, simultaneous
cooling / heating operation)
Main motorized valve (EV1)
Depend on heat exchanger
mode (heating, simultaneous
cooling / heating operation)
Sub motorized valve (EV2)
Depend on heat exchanger
mode (heating, simultaneous
cooling / heating operation)
Sub-cooling motorized valve (EV3) PI control (EV3 control)
Hot gas bypass valve (SVP) OFF
This valve turns on with low pressure protection
control.
Oil equalization valve (SVO) Oil level equalizing control
In the case of multi-outdoor-unit system, this valve
repeats ON/OFF operation at regular intervals of
time.
Receiver gas charging valve (SVL) OFF
This valve turns on when outdoor temperature is
low.
Receiver gas discharge valve (SVG) ON
Discharge pipe stop valve (SVR) OFF
Non-operating unit liquid pipe stop valve
(SVSL)
OFF
High pressure gas pipe pressure
reduction valve (SVC)
ON
