SiUS39-602 Specifications
Specifications 11
1.2 Indoor Units
Ceiling Mounted Cassette Type (Multi-flow)
Notes:
★
1 Nominal cooling capacities are based on the following conditions:
Return air temperature: 80°FDB, 67°FWB
Outdoor temperature: 95°FDB
Equivalent ref. piping length: 25ft (Horizontal)
★
2 Nominal heating capacities are based on the following conditions:
Return air temperature: 70°FDB.
Outdoor temperature: 47°FDB, 43°FWB
Equivalent ref. piping length: 25ft (Horizontal)
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
4 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of installation conditions.
Model FXFQ12MVJU FXFQ18MVJU FXFQ24MVJU
★
1 Cooling Capacity Btu/h 12,000 18,000 24,000
★
2 Heating Capacity Btu/h 13,500 20,000 27,000
Casing / Color Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) in 9-1/8
×
33-1/8
×
33-1/8 9-1/8
×
33-1/8
×
33-1/8 9-1/8
×
33-1/8
×
33-1/8
Coil (Cross
Fin Coil)
Rows × Stages × FPI 2
×
8
×
17 2
×
8
×
17 2 × 8 × 17
Face Area ft² 3.56 3.56 3.56
Fan
Model QTS45B14M QTS45B14M QTS45B14M
Type Turbo Fan Turbo Fan Turbo Fan
Motor Output HP 0.06 0.06 0.06
Air Flow Rate (H/L) cfm 460/350 570/390 670/490
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material
Foamed Polystyrene /
Foamed Polyethylene
Foamed Polystyrene /
Foamed Polyethylene
Foamed Polystyrene /
Foamed Polyethylene
Piping
Connections
Liquid Pipes in
φ
1/4 (Flare Connection)
φ
1/4 (Flare Connection)
φ
3/8 (Flare Connection)
Gas Pipes in
φ
1/2 (Flare Connection)
φ
1/2 (Flare Connection)
φ
5/8 (Flare Connection)
Drain Pipe in
VP25
External Dia. 1-1/4
Internal Dia. 1
VP25
External Dia. 1-1/4
Internal Dia. 1
VP25
External Dia. 1-1/4
Internal Dia. 1
Machine Weight (Mass) Lbs 55 55 55
★
4 Sound Level (H/L) dBA 31/28 33/28 34/29
Safety Devices Fuse, Thermal Protector for Fan Motor Fuse, Thermal Protector for Fan Motor Fuse, Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-410A Series R-410A Series R-410A Series
Decoration
Panels
(Option)
Model BYC125K-W1 BYC125K-W1 BYC125K-W1
Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) in 1-5/8
×
37-3/8
×
37-3/8 1-5/8
×
37-3/8
×
37-3/8 1-5/8
×
37-3/8
×
37-3/8
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight Lbs 11 11 11
Standard Accessories
Operation manual, Installation
manual, Paper pattern for installation,
Drain hose, Clamp metal, Washers,
Sealing pads, Clamps, Screws,
Insulation for fitting.
Operation manual, Installation
manual, Paper pattern for installation,
Drain hose, Clamp metal, Washers,
Sealing pads, Clamps, Screws,
Insulation for fitting.
Operation manual, Installation
manual, Paper pattern for installation,
Drain hose, Clamp metal, Washers,
Sealing pads, Clamps, Screws,
Insulation for fitting.
Drawing No. C:3D042686
()()()
