SiUS39-602 Specifications
Specifications 7
Notes:
★
1 Indoor temp. : 80°FDB or 67°FWB / outdoor temp. : 95°FDB / Equivalent piping length : 25 ft, level
difference: 0.
★
2 Indoor temp. : 70°FDB / outdoor temp. : 47°FDB or 43°FWB / Equivalent piping length : 25 ft, level
difference: 0.
★
3 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of ambient conditions.
Model Name REYQ96MTJU
★
1 Cooling Capacity Btu / h 96,000
★
2 Heating Capacity Btu / h 108,000
Casing Color Ivory White (5Y7.5/1)
Dimensions: (H×W×D) in 64 × 48-7/8 × 30-1/8
Heat Exchanger Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 13.72+10.47
Number of Revolutions r.p.m 6480, 2900
Motor Output × Number
of Units
kW (2.7+4.5) × 1
Starting Method Direct on line
Fan
Type Propeller Fan
Motor Output kW 0.75 × 1
Air Flow Rate cfm 7,400
Drive Direct Drive
Connecting
Pipes
Liquid Pipe in 3/8 in C1220T (Flare Connection)
Gas Pipe in 7/8 in C1220T (Brazing Connection)
Discharge Gas Pipe in 3/4 in C1220T (Brazing Connection)
Machine Weight (Mass) Lbs 666
★
3 Sound Level (Reference Value) dBA 60
Safety Devices High Pressure Switch, Fan Driver Overload Protector, Over Current Relay, Inverter Overload Protector, Fusible Plugs
Defrost Method Deicer
Capacity Control % 14~100
Refrigerant
Refrigerant Name R-410A Series
Charge Lbs 27.3
Control Electronic Expansion Valve
Refrigerator
Oil
Synthetic (ether) oil
Charge Volume L 1.9+1.6
Standard Accessories Installation Manual, Operation Manual, Connection Pipes, Clamps
Drawing No. 4D045327A
