Konica Minolta BizHub 3622 [118/202] Replacing the imaging unit
![Konica Minolta BizHub 3622 [118/202] Replacing the imaging unit](/views2/1712901/page118/bg76.png)
5 Close the front door.
Note: Dispose of the empty toner cartridge according to your local regulations. Do not burn the cartridge.
CAUTION—POTENTIAL INJURY: If you get toner in your eyes, wash it out immediately with cool
water and consult a doctor.
Replacing the imaging unit
1 Open the front door.
Maintaining the printer 118
