Konica Minolta BizHub 3622 [90/202] Wireless
![Konica Minolta BizHub 3622 [90/202] Wireless](/views2/1712901/page90/bg5a.png)
Menu item Description
Network Job Timeout
O
On* (90 seconds)
Set the time before the printer cancels a network print job.
Banner Page
O
On*
Print a banner page.
Note: An asterisk (*) next to a value indicates the factory default setting.
Wireless
Note: This menu is available only in printers connected to a wireless network.
Menu item Description
Setup On Printer Panel
Choose Network
Add Wi-Fi Network
Network Name
Network Mode
Infrastructure*
Ad hoc
Wireless Security Mode
Disabled*
WEP
WPA2/WPA - Personal
WPA2 - Personal
Configure the wireless connection using the control panel.
Wi‑Fi Protected Setup
Start Push Button Method
Start PIN Method
Establish a wireless network and enable network security.
Notes:
• Start Push-Button Method connects the printer to a wireless
network when buttons on both the printer and the access point
(wireless router) are pressed within a given period of time.
• Start PIN Method connects the printer to a wireless network
when a PIN on the printer is entered into the wireless settings
of the access point.
Network Mode
BSS Type
Infrastructure*
Ad hoc
Preferred Channel Number
Auto*
1–11
Specify the network mode.
Note: Preferred Channel Number only appears if BSS Type is set to
Ad hoc.
Enable Wi‑Fi Direct
On
O*
Set the printer to connect directly to Wi-Fi devices.
Understanding the printer menus 90
