Menu item Description
Scan Edge to Edge
On
O*
Allow edge‑to‑edge scanning of the original document.
Sharpness
1–5 (3*)
Adjust the sharpness of the scanned image.
Temperature
‑4 to 4 (0*)
Specify whether to generate a cooler or warmer output.
Note: An asterisk (*) next to a value indicates the factory default setting.
Admin Controls
Menu item Description
Automatic Redial
0–9 (5*)
Adjust the number of redial attempts based on the activity levels of recipient fax
machines.
Redial Frequency
1–200 minutes (3*)
Increase the time between redial attempts to increase the chance of sending
fax successfully.
Enable ECM
On*
O
Activate Error Correction Mode (ECM) for fax jobs.
Note: ECM detects and corrects errors in the fax transmission process that are
caused by telephone line noise and poor signal strength.
Enable Fax Scans
On*
O
Fax documents that are scanned at the printer.
Driver to Fax
On*
O
Allow the print driver to send fax.
Allow Save as Shortcut
On*
O
Save fax numbers as shortcuts in the printer.
Max Speed
33600*
14400
9600
4800
2400
Set the maximum speed for sending fax.
Enable Color Fax Scans
O
by default*
On by default
Never use
Always use
Enable color scans for fax.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 73
