Konica Minolta BizHub 3622 [97/202] Understanding the printer menus 97
![Konica Minolta BizHub 3622 [97/202] Understanding the printer menus 97](/views2/1712901/page97/bg61.png)
Menu item Description
Base Configuration
Default*
Compatibility
Secure
Set the IPSec base configuration.
Note: This menu item appears only when Enable IPSec is set to
On.
DH (Die‑Hellman) Group Proposal
modp2048 (14)*
modp3072 (15)
modp4069 (16)
modp6144 (17)
modp8192 (18)
Set the IPSec encryption.
Note: This menu item appears only when Base Configuration is set
to Compatibility.
IKE SA Lifetime (Hours)
1
2
4
8
24*
Set the amount of time before a new authentication key is generated.
Note: These menu items appear only when Base
Configuration
is
set to Secure.
IPSec SA Lifetime (Hours)
1
2
4
8
24*
Proposed Encryption Method
3DES
AES*
Specify the encryption and authentication methods to connect to a
network securely.
Note: These menu items appear only when Base Configuration is
set to Compatibility.
Proposed Authentication Method
SHA1
SHA256*
SHA512
IPSec Device Certificate Specify an IPSec certificate.
Note: This menu item appears only when Base Configuration is set
to Compatibility.
Pre‑Shared Key Authenticated
Connections
Host [x]
Address
Key
Configure the authenticated connections of the printer.
Note: These menu items appear only when Enable IPSec is set to
On.
Certificate Authenticated Connections
Host [x] Address[/subnet]
Address[/subnet]
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 97
