Konica Minolta BizHub 3622 [71/202] Fax send settings
![Konica Minolta BizHub 3622 [71/202] Fax send settings](/views2/1712901/page71/bg47.png)
Menu item Description
Optimize Fax Compatibility Configure the printer fax functionality for optimal compatibility with other fax
machines.
Note: An asterisk (*) next to a value indicates the factory default setting.
Fax Send Settings
Menu item Description
Resolution
Standard*
Fine
Super Fine
Ultra Fine
Set the resolution of the scanned image.
Note: A higher resolution increases fax transmission time and requires higher
memory.
Original Size
[List of paper sizes]
Specify the size of the original document.
Note: Mixed Sizes is the U.S. factory default setting. A4 is the international
factory default setting.
Orientation
Portrait*
Landscape
Specify the orientation of the original document.
Sides
O*
Long Edge
Short Edge
Specify the page orientation of text and graphics when scanning a two‑sided
document.
Content Type
Te xt*
Te xt/ P ho to
Graphics
Improve the output result based on the content of the original document.
Content Source
Black and White Laser
Color Laser*
Inkjet
Photo/Film
Magazine
Newspaper
Press
Other
Improve the output result based on the source of the original document.
Darkness
1–9 (5*)
Adjust the darkness of the scanned image.
Behind a PABX
On
O*
Set the printer to dial a fax number without waiting to recognize the dial tone.
Note: Private Automated Branch Exchange (PABX) is a telephone network that
allows a single access number to oer multiple lines to outside callers.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 71
