Konica Minolta BizHub 3622 [88/202] Admin controls
![Konica Minolta BizHub 3622 [88/202] Admin controls](/views2/1712901/page88/bg58.png)
Menu item Description
Contrast
Best for content*
0
1
2
3
4
5
Specify the contrast of the output.
Background Removal
Background Detection
Content‑based*
Fixed
Level
‑4 to 4 (0*)
Adjust the amount of background visible on a scanned image.
Mirror Image
On
O*
Create a mirror image of the original document.
Negative Image
On
O*
Create a negative image of the original document.
Shadow Detail
‑4 to 4 (0*)
Adjust the amount of shadow detail visible on a scanned image.
Scan Edge to Edge
O*
On
Allow edge‑to‑edge scanning of the original document.
Sharpness
1–5 (3*)
Adjust the sharpness of a scanned image.
Temperature
‑4 to 4 (0*)
Specify whether to generate a bluer or a redder output.
Blank Pages
Blank Page Removal
Blank Page Sensitivity
Specify whether to include blank pages.
Note: An asterisk (*) next to a value indicates the factory default setting.
Admin Controls
Menu item Description
Text Default
5–95 (75*)
Set the quality of text on a scanned image.
Text/Photo Default
5–95 (75*)
Set the quality of text or photo image on a scanned image.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 88
