![Konica Minolta BizHub 3622 [80/202] Understanding the printer menus 80](/img/pdf.png)
Konica Minolta BizHub 3622 [80/202] Understanding the printer menus 80
![Konica Minolta BizHub 3622 [80/202] Understanding the printer menus 80](/views2/1712901/page80/bg50.png)
Menu item Description
Use Active Directory Device
Credentials
O
On*
Enable user credentials and group designations to connect to the SMTP server.
Device Userid Specify the user ID and password to connect to the SMTP server.
Device Password
Kerberos 5 REALM Specify the realm for the Kerberos 5 authentication protocol.
NTLM Domain Specify the domain name for the NTLM security protocol.
Disable "SMTP server not set
up" error
O*
On
Hide the “SMTP server not set up” error message.
Note: An asterisk (*) next to a value indicates the factory default setting.
E‑mail Defaults
Menu item Description
Subject Specify the e‑mail subject and message.
Message
File Name Specify the filename for the scanned image.
Format
PDF (.pdf)*
TIFF (.tif)
JPEG (.jpg)
XPS (.xps)
Specify the file format for the scanned image.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 80
