Konica Minolta BizHub 3622 [70/202] Understanding the printer menus 70
![Konica Minolta BizHub 3622 [70/202] Understanding the printer menus 70](/views2/1712901/page70/bg46.png)
Menu item Description
Fax ID
Fax Name
Fax Number*
Notify fax recipients of your fax name or fax number.
Enable Manual Fax
O*
On
Set the printer to fax manually.
Notes:
• This setting requires a line splitter and a telephone handset.
• Use a regular telephone line to answer an incoming fax job and to dial a
fax number.
• To go directly to the Manual Fax function, touch # and 0 on the keypad.
Memory Use
All receive
Mostly receive
Equal*
Mostly send
All send
Set the amount of internal printer memory allocated for faxing.
Note: This setting prevents memory
buer
conditions and failed faxes.
Cancel Faxes
Allow*
Don't Allow
Cancel outgoing faxes before they are transmitted, or cancel incoming faxes
before they finish printing.
Caller ID
O
On*
Alternate
Show the telephone number of the person sending the fax.
Fax Number Masking
O*
From Left
From Right
Specify the format for masking an outgoing fax number.
Digits to Mask
0–58 (0*)
Specify the number of digits to mask in an outgoing fax number.
Enable Line Connected
Detection
O
On*
Determine whether a telephone line is connected to the printer.
Note: Detection takes place when turning on the printer and before each call.
Enable Line In Wrong Jack
Detection
O*
On
Determine whether a telephone line is connected to the correct port on the
printer.
Note: Detection takes place when turning on the printer and before each call.
Enable Extension in Use
Support
O
On*
Determine whether a telephone line is used by another device such as another
phone on the same line.
Note: This setting is monitored continuously after turning on the printer.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 70
