Menu item Description
Photo Default
5–95 (50*)
Set the quality of a photo image on a scanned image.
Use Multi‑Page TIFF
On*
O
Choose between single- and multiple‑page TIFF files.
TIFF Compression
LZW*
JPEG
Set a compression option for TIFF files.
Transmission Log
Print Log*
Do Not Print Log
Print Only For Error
Print a log for successful FTP scan transmission.
Log Paper Source
Tray [x] (1*)
MP Feeder
Specify the paper source for printing FTP logs.
Note: An asterisk (*) next to a value indicates the factory default setting.
Network/Ports
Network Overview
Menu item Description
Active Adapter
Auto*
Standard Network
Wireless
Choose the network connection that the printer connects to.
Network Status Show the connection status of the printer network.
Display Network Status on
Printer
O
On*
Show the network status on the display.
Speed, Duplex Show the speed of the currently active network card.
IPv4 Show the IPv4 address.
All IPv6 Addresses Show all IPv6 addresses.
Reset Print Server
Start
Reset all active network connections to the printer.
Note: This setting removes all network configuration settings.
Note: An asterisk (*) next to a value indicates the factory default setting.
Understanding the printer menus 89
