WSG-404 User Guide
40
Basic Configuration
SSID: The SSID is the unique name shared among all devices in a wireless network. The SSID
must be the same for all devices in the wireless network. It is case sensitive, must not exceed 32
characters and may be any character on the keyboard. Administrators can give a new name in
this field or use the default name.
Sync to Ticket: Synchronize the SSID of ticket with this system.
Channel: Select the appropriate channel from the list to correspond to the network settings; for
example, 1 to 11 channels are suitable for the North America area. All points in the wireless
network must use the same channel in order to make sure correct connection.
Transmission Mode: There are 2 modes to select from, 802.11b (2.4G, 1~11Mbps) and 802.11
(b+g) (2.4G, 1~11Mbps and 2.4G, 54Mbps).
SSID Broadcast: Select to enable the SSID broadcast in the network. When configuring the
network, this function may be enabled but should be disabled when configuration is finished.
Since when SSID Broadcast is enabled, someone could easily obtain the SSID information with
the site survey software and get unauthorized access to the network.
Layer2 Client Isolation: This function can be enabled to isolate any client from each other.
Security: For security settings in detail, please click the hyperlink Security to go into the
Security page. Choose “Enable” to configure the setting.
