Si37-701 Special Control
Function 121
3.5.2 Pump-down Residual Operation in Heating Operation and
Simultaneous Cooling / Heating Operation
* Pe_min and Pc_max indicate the minimum and maximum values in the system, respectively.
Actuator Symbol
Elect.
symbol
Master unit operation Slave unit operation
Compressor 1
—
M1C
124 Hz+OFF+OFF OFFCompressor 2 M2C
Compressor 3 M3C
Outdoor unit fan 1
—
M1F
Fan control Fan control
Outdoor unit fan 2 M2F
Electronic expansion valve (Main) EVM
Y1E
Y3E
When 20SA=ON: 0 pls
When 20SA=OFF: 1375 pls
When 20SA=ON: 0 pls
When 20SA=OFF: 1375 pls
Electronic expansion valve
(Supercooling)
EVT
Y2E
Y5E
0 pls 0 pls
Electronic expansion valve
(Refrigerant charge)
EVJ Y4E 80 pls 80 pls
Four way valve (Heat exchanger
switch)
20SA
Y2S
Y9S
When outdoor heat
exchanger is evaporator: ON
When outdoor heat
exchanger is condenser: OFF
When outdoor heat
exchanger is evaporator: ON
When outdoor heat
exchanger is condenser: OFF
Four way valve (High/low pressure
gas pipe switch)
20SB Y8S OFF OFF
Solenoid valve (Main bypass)
SVE
Y5S
Y10S
OFF OFF
Solenoid valve (Hot gas) SVP Y4S OFF OFF
Solenoid valve (Refrigerant
regulator liquid pipe )
SVL Y3S OFF OFF
Solenoid valve (Refrigerant
regulator gas vent pipe)
SVG Y1S OFF OFF
Solenoid valve (Refrigerant
regulator exhaust pipe)
SVO Y7S OFF OFF
Solenoid valve (Refrigerant
regulator discharge pipe)
SVT Y6S OFF OFF
Ending conditions
• 3 min.
• Pe_min<0.25 MPa ∗
• Pc_max<3.13 MPa ∗
• Master unit Tdi>110°C
• Master unit Tp>140°C
or
