Troubleshooting by Indication on the Remote Controller Si37-701
280 Troubleshooting
3.35
“L1”
Outdoor Unit: Defective Inverter PC Board
Remote
Controller
Display
L1
Applicable
Models
REYQ8P~48P
Method of
Malfunction
Detection
Malfunction is detected based on the current value during waveform output before starting
compressor.
Malfunction is detected based on the value from current sensor during synchronous operation
when starting the unit.
Malfunction
Decision
Conditions
Overcurrent (OCP) flows during waveform output.
Malfunction of current sensor during synchronous operation.
IPM failure.
Supposed
Causes
Inverter PC board (A2P)
z
IPM failure
z
Current sensor failure
z
Drive circuit failure
Troubleshooting
Check if
the unit recovers to
normal operation.
Check 4
Check if the power
transistor is
normal.
YES
Check if
insulation resistance of
the compressor is 100kΩ
and above.
NO
YES
Check 4
Check if the power
transistor of the fan
driver is normal.
NO
NO
YES
Power off the unit then
supply power again.
YES
NO
There are some other possible
external factors except failure.
(External noise, thunder, etc.)
Replace the compressor and
compressor inverter PC board
(A2P) at the same time.
Replace the inverter PC board
(A2P).
Replace the compressor inverter
PC board (A2P) and fan inverter
PC board (A5P).
Replace the inverter PC board
(A2P).
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
∗
∗
∗
Check 4
: Referring to the information on P339.
