Specifications Si37-701
10 Specifications
1. Specifications
1.1 Outdoor Units
Heat Recovery 50Hz <REYQ-P>
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference
: 0m.
4 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as
REYQ8PY1E.
Model Name REYQ8PY1(E) REYQ10PY1(E)
★
1 Cooling Capacity (19.5°CWB)
kcal / h 19,400 24,300
Btu / h 76,800 96,200
kW 22.5 28.2
★
2 Cooling Capacity (19.0°CWB) kW 22.4 28.0
★
3 Heating Capacity
kcal / h 21,500 27,100
Btu / h 85,300 107,000
kW 25.0 31.5
Casing Color
Y1 Type Ivory White 5Y7.5/1 Ivory White 5Y7.5/1
Y1E Type Light Camel 2.5Y6.5/1.5 Light Camel 2.5Y6.5/1.5
Dimensions: (H×W×D) mm 1680×1300×765 1680×1300×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 7.88+10.53 13.34+10.53
Number of Revolutions r.p.m 3720, 2900 6300, 2900
Motor Output×Number
of Units
kW 1.0+4.5 2.2+4.5
Starting Method Soft Start Soft Start
Fan
Type Propellor Fan Propellor Fan
Motor Output kW 0.35×2 0.35×2
Air Flow Rate
I/s 3,166 3,166
m³/min 190 190
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe
φ
9.5 C1220T (Brazing Connection)
φ
9.5 C1220T (Brazing Connection)
Suction Gas Pipe
φ
19.1 C1220T (Brazing Connection)
φ
22.2 C1220T (Brazing Connection)
High and Low Pressure Gas Pipe
φ
15.9 C1220T (Brazing Connection)
φ
19.1 C1220T (Brazing Connection)
Pressure Equalizer Tube — —
Mass (Weight) kg 311 331
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
Defrost Method Deicer Deicer
Capacity Control % 20~100 14~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 10.3 10.6
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. 4D057563 4D057564
The Reference Number
C~: Partly corrected drawings.
J~ : Original drawing is Japanese
V~: Printing Convenience
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
