8
Chapter 3: Using the UniFi Controller SoftwareUniFi
™
AP-Outdoor User Guide
Ubiquiti Networks, Inc.
Alerts
Important events are displayed in the alerts window. The
date and time of the event and the message are displayed.
Search Allows you to enter text you want to search for.
Simply begin typing; there is no need to press Enter.
Show Archived Show all of the alert messages that have
been archived.
Archive All Archive all of the alert messages displayed on
the screen.
Adopt Click to adopt an Access Point that is waiting for
adoption.
Archive Archive the selected alert message.
Settings
System System related settings.
Guest Control Guest portal and policies.
Wireless Networks Wireless networks.
Blocked Devices List of blocked wireless
devices.
>_
Admin Settings Admin username, password,
and preferences.
User Groups User Group settings.
Settings > System
System Configuration
System Name Editable field with the system name.
Country Select your country from the drop-down list.
Services
Automatic Upgrade When enabled, this option will
automatically upgrade your firmware when an update is
available.
LED When enabled, the LED on the Access Point will light
up. When disabled, the LED will turn off.
Background Scanning When this option is enabled, all
managed Access Points will scan in the background for
“Rogue Access Points” – third-party or UniFi Access Points
that are being managed by another instance of the UniFi
Controller software. This option is disabled by default.
• Scan Now When clicked, all managed Access Points
will scan across all maps for two to three seconds. New
Access Points in their default state will appear under
Access Points > Pending.
Load Balancing Sets a desired number of clients per AP.
While an AP will allow more clients to connect, it will start
to look at those with lower signals and disconnect them.
Network Discovery When enabled, this option allows
UniFi to be discoverable via UPnP. This option is disabled
by default.
Uplink Connectivity Monitor It monitors the uplinks of
the managed Access Points, either wired or wireless, by
checking to see if the gateway/custom IP can be reached.
The monitor and wireless uplink capability are enabled by
default.
• Use default gateway Use default gateway is selected by
default; all managed Access Points will use the gateway
of the Access Point that is providing IP information,
either by DHCP or Static designation.
• Use custom IP Select Use custom IP to specify an
IP address; all managed Access Points will use the IP
address you enter in the Uplink IP address field.
