44
Appendix A: Portal CustomizationUniFi
™
AP-Outdoor User Guide
Ubiquiti Networks, Inc.
Appendix A: Portal
Customization
Overview
With Portal Customization, the UniFi Controller software
allows complete branding of a portal implementation,
allowing you to “white label” your wireless internet service
as if you had developed it yourself.
In order to provide the maximum flexibility in your
branding effort, the UniFi Controller software provides
total access to the portal directory on the system in which
it is installed.
This open architecture allows you to include unlimited
content while keeping development simple through the
use of plain .html (hand code or use any editor of your
choice). Testing is simple and immediate by reloading
changes from any browser.
Enabling Portal Customization
By default, Portal Customization is disabled in all Guest
Portal implementations. See “Settings > Guest Control”
on page 9 for more information on enabling the Guest
Portal for the following authentication and landing page
options: No authentication, Simple Password, Hotspot.
To enable Portal Customization, perform the following
steps:
1. Go to Settings and select Guest Control.
2. Make sure that the Guest Portal is enabled and select
an authentication method.
3. Select Enable portal customization and click Apply.
Viewing the Default Portal
Once Guest Portal > Portal Customization is enabled,
connect to the Guest Network SSID as shown below,
depending on your platform.
Windows
1. Go to Connect to Network.
- Windows 7 Right-click the Network icon.
- Windows Vista Go to Start > Connect To.
- Windows XP Right-click the Wireless Network icon
in the System Tray (lower right corner of the screen)
and then click View Available Wireless Networks.
2. Select the Guest Network SSID and click Connect.
3. Depending on the security type applied to the
network, enter the security key or password. Click OK
or Connect.
4. Launch your Web browser and you will be directed
to the default portal page for the authentication type
configured on the Guest Portal (see “Settings > Guest
Control” on page 9 for screenshots of default
portal pages by authentication method).
Mac
1. Click the AirPort icon in the menu bar (top left side
of the screen).
2. Select the Guest Network SSID and click Connect.
3. Depending on the security type applied to the
network, enter the security key or password. Click OK.
4. Once connected, the AirPort icon will change from
gray to solid black. The number of black lines indicates
the signal strength.
5. Launch your Web browser and you will be directed
to the default portal page for the authentication type
configured on the Guest Portal (see “Settings > Guest
Control” on page 9 for screenshots of default
portal pages by authentication method).
Setup
The html and css files are located on the system that the
UniFi Controller software has been installed on. The file
paths are in the following locations:
Mac:
/Applications/UniFi.app/Contents/Resources/data/portal
Windows:
<Drive_Letter>:\Users\<Username>\Ubiquiti UniFi\data\
portal
For specific instructions on accessing the files, refer to the
specific operating system:
