Ubiquiti UniFi AP Outdoor [51/58] Appendix c specifications
![Ubiquiti UniFi AP Outdoor [51/58] Appendix c specifications](/views2/1072883/page51/bg33.png)
48
Appendix C: SpecificationsUniFi
™
AP-Outdoor User Guide
Ubiquiti Networks, Inc.
Appendix C: Specifications
UniFi AP-Outdoor (UAP-Outdoor)
Dimensions 17 x 8 x 3 cm
Weight 230 g (without Antennas)
274 g (with Antennas)
Networking Interface (2) 10/100 Ethernet Ports
Buttons Reset
Antennas (2) External 6 dBi Omni Antennas Included
191 mm (Length), 13 mm (Diameter)
Wi-Fi Standards 802.11 b/g/n*
Power Method Passive Power over Ethernet (12-24V)
Power Supply 24V, 1A PoE Adapter Included
Max. Power Consumption 4.6W
Max. TX Power 27 dBm
BSSID Up to Four per Radio
Power Save Supported
Wireless Security WEP, WPA-PSK, WPA-TKIP,
WPA2 AES, 802.11i
Certications CE, FCC, IC
Mounting Wall and Pole (Kits Included)
Operating Temperature -30 to 75°C (-22 to 167° F)
Operating Humidity 5 to 95% Condensing
Advanced Trafc Management
VLAN 802.1Q
Advanced QoS Per-User Rate Limiting
Guest Trafc Isolation Supported
WMM Voice, Video, Best Effort, and Background
Concurrent Clients 100+
Supported Data Rates (Mbps)
Standard Data Rates
802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
* 2.4 GHz
