25
Chapter 7: Users TabUniFi
™
AP-Outdoor User Guide
Ubiquiti Networks, Inc.
Chapter 7: Users Tab
The Users tab displays a list of users that are connected to
the primary wireless network of the Access Point.
Search Allows you to enter text you want to search for.
Simply begin typing; there is no need to press Enter.
• 2G Select if you only want users of the 2.4 GHz wireless
network displayed.
• 5G Select if you only want users of the 5 GHz wireless
network displayed.
• All Select to show all users.
Filter by AP Drop-down list of all available Access Points.
Select one to filter the results and display only users
connected to the selected Access Point.
Page Size Allows you to determine how many results are
displayed per page. Select 10, 20, 30, 40, 60, or 100.
Name/MAC Address Displays the hostname, alias, or
MAC address of the connected user. You can click the
name to get additional details.
IP Address Displays the IP address assigned to the user.
WLAN Displays the name of the SSID (network name) of
the wireless LAN (WLAN) that the user is connected to.
Access Point Displays the hostname or alias of the Access
Point. You can click the name to get additional details on
the Access Point.
Signal Displays the signal strength and type from the
Access Point to the client. If a lightning bolt symbol is
present, the device is in power save mode. The device will
return to active mode when Down or Up activity resumes.
Icon Clients Mode
a
5 GHz (either 802.11a or 802.11n/a) Active
a
5 GHz (either 802.11a or 802.11n/a) Power Save
n
2.4 GHz (802.11n) Active
n
2.4 GHz (802.11n) Power Save
g
2.4 GHz (802.11g) Active
g
2.4 GHz (802.11g) Power Save
b
2.4 GHz (802.11b) Active
b
2.4 GHz (802.11b) Power Save
Down Displays the total bytes of data received by the
user.
Up Displays the total bytes of data sent by the user.
