Chapter 8: Guests TabUniFi

™

AP-Outdoor User Guide

Ubiquiti Networks, Inc.

Activity Displays the level of activity for each guest.

Bars Activity Level

(Bytes per second)

Idle

500

8000

64000

512000

2048000

Uptime Displays the total time the guest has been

connected for this session.

Actions Click an action button to perform the

appropriate action.

• Block Click this button to block a specific guest from

accessing the Access Point.

• Reconnect Click this button to reconnect a specific

guest to the Access Point.

• Authorize When a guest is in a pending state,

authorization can be granted here manually.

• Unauthorize Removes authorization of wireless guest

access and disconnects the client.
