New2001
4
2
PANEL DESCRIPTION
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
AquaQuake [ ] (p. 16)
While holding down, the AquaQuake function is activated
to clear water away from the speaker grill.
Favorite channel [
] (p. 18)
Push to set or clear the displayed channel as a Favorite ➥
(Tag) channel.
Hold down for 3 seconds to clear or set all Favorite ➥
channels in the selected channel group.
Name [
] (p. 13)
Push to enter the channel name programming mode.
Backlight [
] (p. 16)
Push to enter the LCD and key backlight brightness ad-
justment mode.
•Whileintheadjustmentmode,push[∫]/[√]/[Ω]/[≈] or rotate Dial
to adjust the brightness of the LCD and key backlight.
LO/DX [ ]* (p. 11)
Push to turn the Attenuator function ON or OFF.
•“LOCAL”appearswhentheAttenuatorfunctionisON.
*Only U.S.A. and Australian version transceivers.
Log [ ] (p. 63)
Push to enter “RCVD CALL LOG” in the DSC CALLS menu.
