Metabo P 3000 G [12/44] Technical specifications
12
ENGLISH
For this equipment the following – and
further – accessories are available at
specialist dealers.
A Sto
ck no. 090 304 0521:
Pump Installation Package,
complete with double nipple, check
valve, filter short, washable filter
cartridge, spiral hose assembly
1 m, thread sealing tape.
B Sto
ck no. 090 306 3238:
Hydromat HM 2, 230 V
for automatic starting when water is
draw
n and stopping when no water
is drawn, keeps the pump from run-
ning dry.
C Sto
ck no. 090 305 2597:
Hydrostop, 230 V
for automatic stopping when there
is a lack of water, prevents the
pump from running dry.
D Sto
ck no. 090 302 8521:
Dry-running Stop Switch, 230 V
with 10 m cable, keeps the pump
from running dry when pumping
from tank, pool, etc.
E Sto
ck no. 090 300 4258:
Spiral Suction Hose 1", 4 m, c/w
qui
ck release screw fitting and
strainer with foot valve;
Stock no. 090 301 1858:
Spiral Suction Hose 1", 7 m, c/w
qui
ck release screw fitting and
strainer with foot valve;
F Sto
ck no. 090 302 8351:
Disposable Filter Cartridg
e, long;
Stock no. 090 302 8432:
Disposable Filter Cartridge, short;
for mechanical prefiltering of sand.
G Stock no. 090 302 8360:
Washable Filter Cartridge, long;
Stock no. 090 302 8440:
Washable Filter Cartridge, short;
for mechanical prefiltering of sand,
reusable.
H Sto
ck no. 090 301 6817:
Pipe Nipple 150 mm, 1" male at
both
ends, galvanized, to connect
pump and filter.
I Sto
ck no. 090 301 8402:
Double Nipple, 1" male at boths
end
s.
J Sto
ck no. 090 302 8203:
Check Valve 1" female, prevents
water
backflow and pump running
dry.
K Sto
ck no. 090 102 6319:
Thread Sealing Tape, 12 m roll.
(AG=male, IG=female)
11. Available Accessories
12. Technical Specifications
Mains voltage V 230 1 110 1
Frequency Hz 50 60
Rated output W 900 950
Rated current A 3.7 9.7
Fuse protection min. (time-lag or L-type circuit breaker) A 10 15
Running capacitor F 16 35
Rated speed min
-1
2900 3400
Pump capacity max. l/h 3000 3000
Delivery head max. m 43 43
Delivery pressure max. bar 4.3 4.3
Max. suction head m 8.5 8.5
Temperature of the primed medium max. °C 35 35
Ambient temperature °C 5 … 40 5 … 40
Degree of protection IP X4 IP X4
Protection class I I
Insulation class B B
Materials
Pump casing
Pump shaft
Impeller
Grey cast iron
Stainless steel
Noryl
Grey cast iron
Stainless steel
Noryl
Connections (IG=female thread)
Pump inlet
Discharge port
1" IG
1" IG
1" IG
1" IG
Dimensions (without connections)
Length
Width
Height
mm
mm
mm
375
185
250
375
185
250
Weights
Dry weight
Weight filled with water
kg
kg
14.0
14.5
14.0
14.5
Noise emission values (at max. pressure)
Sound power level L
WAd
dB (A) 75.0 75.0
Max. length of extension cable
at 3 x 1.0 mm
2
lead cross-section
at 3 x 1.5 mm
2
lead cross-section
m
m
30
50
10
20
