7
EN
After longer periods of working at low speed,
allow the machine to cool down by running it for a
few minutes at high speed with no load
Height setting of the router column
Fig. B
The clamping lever (10) is used to set the
maximum height of the router.
The plunge depth is then fixed. This is usually
necessary when using the tool on a special router
table. Make sure the router column is not locked.
The router can be pushed down against the
spring force. Lock the router column using the
clamping lever The router is now locked and will
no longer return to its original position.
Adjusting the routing depth
• Place the machine on the workpiece.
• Undo the wing screw (8) and fixing handle (10).
• Slowly move the machine downwards until the
cutter makes contact with the workpiece.
• Tighten the fixing handle (10).
• Set the depth stop (9) to the required routing
depth using the scale and secure it with the
wing screw (8).
• Test the setting by completing a test cut on a
waste piece.
Adjustment using the revolver- depth stop
The revolver-depth stop enables you to quickly
choose between six different cutting depths.
These are also determined by the adjustment of
the depth stop (9).
For larger routing depths, it is recommended
to carry out several repetitive cuts with lower
removal rates.
• Adjust the required cutting depth by pressing
the revolver-depth stop downwards and
rotating the revolver-depth stop (16).
Using the centre pin
Fig. G
• To use the centre pin, insert one guide rod (15)
with the centre pin (20) attached into the holes,
either side of the base plate of the router.
• Secure the guide fence rod to the router at the
required length be rotating the fixing screw (4)
clockwise.
5. MAINTENANCE
Make sure that the machine is not live
when carrying out maintenance work on
the motor.
These machines have been designed to operate
over a long period of time with a minimum of mainte-
nance. Continuous satisfactory operation depends
upon proper machine care and regular cleaning.
Cleaning
Regularly clean the machine housing with a
soft cloth, preferably after each use. Keep the
ventilation slots free from dust and dirt. If the dirt
does not come off use a soft cloth moistened with
soapy water. Never use solvents such as petrol,
alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
Troubleshooting
Please find some potential causes and solutions
to possible failure.
1 The operating switch is switched on, but
the motor is not working
• The electric circuit is broken
• Have the electric circuit repaired
• Wires in the mains plug or in the socket are
loose
• Have socket and plug checked or repaired
• The switch is faulty
• Have the switch repaired
• Carbon brushes are worn
• Replace the carbon brushes
2 Router runs slowly
• Variable speed set low
• Increase variable speed
• Motor is overloaded
• Reduce pushing force on router
3 Excessive vibration
• Bent cutter shank
• Replace cutter
Faults
Should a fault occur, e.g. after wear of a part,
please contact the adress on the warranty card.
Included you find an exploded view showing the
parts that can be ordered.
