List of Functions SiBE18-821
4 List of Functions
Category Functions
FTXS60/71FV1B
Category Functions
FTXS60/71FV1B
Basic
Function
Inverter (with Inverter Power Control) { Health &
Clean
Air Purifying Filter —
Operation Limit for Cooling (°CDB) — Photocatalytic Deodorizing Filter —
Operation Limit for Heating (°CWB) —
Air Purifying Filter with Photocatalytic
Deodorizing Function
—
PAM Control —
Titanium Apatite Photocatalytic
Air-Purifying Filter
{
Standby Electricity Saving —
Compressor Oval Scroll Compressor — Longlife Filter (Option) —
Swing Compressor — Air Filter
{
Rotary Compressor — Wipe-clean Flat Panel
{
Reluctance DC Motor — Washable Grille —
Comfortable
Airflow
Power-Airflow Flap — Filter Cleaning Indicator —
Power-Airflow Dual Flaps
{
Mold Proof Operation —
Power-Airflow Diffuser — Heating Dry Operation —
Wide-Angle Louvers
{
Good-Sleep Cooling Operation —
Vertical Auto-Swing (Up and Down)
{
Timer Weekly Timer —
Horizontal Auto-Swing (Right and Left)
{
24-Hour On/Off Timer
{
3-D Airflow
{
72-Hour On/Off Timer —
Comfort Airflow Mode — Night Set Mode
{
3-Step Airflow (H/P Only) — Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure)
{
Comfort
Control
Auto Fan Speed
{
Self-Diagnosis (Digital, LED) Display
{
Indoor Unit Quiet Operation
{
Wiring-Error Check —
Night Quiet Mode (Automatic) — Automatic Test Operation —
Outdoor Unit Quiet Operation (Manual) — Memory Function —
INTELLIGENT EYE
{
Anticorrosion Treatment of Outdoor
Heat Exchanger
—
2 Area INTELLIGENT EYE —
Flexibility Multi-Split / Split Type Compatible
Indoor Unit
{
Quick Warming Function — H/P, C/O Compatible Indoor Unit —
Hot-Start Function
{
Flexible Voltage Correspondence —
Automatic Defrosting — High Ceiling Application —
Operation Automatic Operation
{
Chargeless —
Programme Dry Function
{
Either Side Drain (Right or Left)
{
Fan Only
{
Power-Selection —
Lifestyle
Convenience
New POWERFUL Operation
(Non-Inverter)
—
Remote
Control
5-Rooms Centralized Controller
(Option)
{
Inverter POWERFUL Operation
{
Remote Control Adaptor
(Normal Open-Pulse Contact) (Option)
{
Priority-Room Setting —
Remote Control Adaptor
(Normal Open Contact) (Option)
{
Cooling / Heating Mode Lock —
DIII-NET Compatible (Adaptor)
(Option)
{
HOME LEAVE Operation
{
Remote
Controller
Wireless
{
ECONO Mode — Wired —
Indoor Unit On/Off Switch
{
Signal Reception Indicator
{
Temperature Display —
Another Room Operation —
Note:
{
: Holding Functions
— : No Functions
