SiBE18-821 Troubleshooting for Outdoor Unit
Troubleshooting 311
7.8 Refrigerant Overcharged
Remote
Controller
Display
F6
Applicable
Models
All outdoor unit models
Method of
Malfunction
Detection
Excessive charging of refrigerant is detected by using the heat exchanging deicer temperature
during a check operation.
Malfunction
Decision
Conditions
When the amount of refrigerant, which is calculated by using the heat exchanging deicer
temperature during a check run, exceeds the standard.
Supposed
Causes
Refrigerant overcharge
Misalignment of the thermistor for heat exchanger
Defect of the thermistor for heat exchanger
Troubleshooting
∗
Refer to “Thermistor Resistance / Temperature Characteristics” table on P349.
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Remove the heat exchanging
deicer thermister from the
outdoor PCB and measure
resistance with a tester.
Check the mounting condition
of the temperature sensors of
the heat exchanging deicer
thermistor in the piping.
Are the
above thermistor
installed on pipes
correctly?
Is the
characteristic of the
above thermistor
normal?
Refrigerant overcharged.
(Q0557)
Install thermistor correctly.
NO
Replace thermistor.
NO
YES
YES
