Troubleshooting for SkyAir Indoor Unit SiBE18-821
288 Troubleshooting
5.11 Malfunction of Remote Controller Thermistor
Remote
Controller
Display
CJ
Applicable
Models
FFQ, FHQ
Method of
Malfunction
Detection
Even if remote controller thermistor is faulty, system is possible to operate by system thermistor.
Malfunction detection is carried out by temperature detected by remote controller thermistor.
Malfunction
Decision
Conditions
When the remote controller thermistor becomes disconnected or shorted while the unit is
running.
Supposed
Causes
Failure of sensor itself
Broken wire
Troubleshooting
Check No.02
Refer to P.293
Turn the power supply off
once and then back on.
Is CJ displayed on the
remote controller?
Replace remote controller.
Could be outside cause
(noise,etc.) other than
malfunction
NO
YES
(Q0541)
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
+See Check No. 02 for “Thermistor temperature and resistance characteristics”.
