SiBE18-821 Specifications
Specifications 19
Ceiling Mounted Cassette Type
50Hz 230V
★
( ) : dimension including control box
Model
FFQ25B8V1B FFQ35B8V1B
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Decoration
Panel
Color White White
Dimensions (H×W×D) 55×700×700 55×700×700
Airflow Rates
m³/min
(cfm)
H 9.0 (318) 9.0 (318) 10.0 (353) 10.0 (353)
M
————
L 6.5 (230) 6.5 (230) 6.5 (230) 6.5 (230)
SL
————
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Air Filter
——
Running Current (Rated) A 0.37 0.32 0.40 0.36
Power Consumption (Rated) W 73 64 84 76
Power Factor % 85.8 87.0 91.3 91.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D)
★
mm 260(286)×575×575 260(286)×575×575
Packaged Dimensions (H×W×D) mm 370×687×674 370×687×674
Weight kg 17.5 17.5
Gross Weight kg 21 21
Operation
Sound
H/L dBA 29.5/24.5 29.5/24.5 32.0/25.0 32.0/25.0
Sound Power H dBA 46.5
—
49.0
—
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm VP20 (O.D
φ
26 / I.D
φ
20) VP20 (O.D
φ
26 / I.D
φ
20)
Drawing No. 3D040445 3D040443
Model
FFQ50B8V1B FFQ60B8V1B
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 6.0kW Class
Decoration
Panel
Color White White
Dimensions (H×W×D) 55×700×700 55×700×700
Airflow Rates
m³/min
(cfm)
H 12.0 (424) 12.0 (424) 15.0 (530) 15.0 (530)
M
————
L 8.0 (283) 8.0 (283) 10.0 (353) 10.0 (353)
SL
————
Fan
Type Turbo Fan Turbo Fan
Motor Output W 55 55
Speed Steps 2 Steps 2 Steps
Air Direction Control Horizontal, Downward Horizontal, Downward
Air Filter
——
Running Current (Rated) A 0.49 0.45 0.61 0.56
Power Consumption (Rated) W 97 89 120 111
Power Factor % 86.1 86.0 85.5 86.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D)
★
mm 260(286)×575×575 260(286)×575×575
Packaged Dimensions (H×W×D) mm 370×687×674 370×687×674
Weight kg 17.5 17.5
Gross Weight kg 21 21
Operation
Sound
H/L dBA 36.0/27.0 36.0/27.0 41.0/32.0 41.0/32.0
Sound Power H dBA 53.0
—
58.0
—
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm VP20 (O.D
φ
26 / I.D
φ
20) VP20 (O.D
φ
26 / I.D
φ
20)
Drawing No. 3D040441 3D040436
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
