Special Control SiBE18-821
66 Function
3.2 Oil Return Operation
Oil flown from the compressor to the side of system is collected by oil-returning operation, in
case of that oil in the compressor runs down.
3.2.1 Oil Return Operation in Cooling Operation
[Conditions to start]
The cooling oil-returning operation is started referring following conditions.
Integrated amount of displaced oil
Timer
(After the power is turned on, integrated operating-time is 2 hours and subsequently every 8
hours.)
In addition, integrated amount of displaced oil is derived from Tc, Te, and the compressor
load.
Outdoor unit actuator
Oil return preparation
operation
Oil return operation Post-oil-return operation
Compressor
Take the current step as the
upper limit.
52 Hz Full load
(→ Low pressure constant
control)
Same as the
“
oil return
operation
”
mode.
Outdoor unit fan Fan control (Normal cooling) Fan control (Normal cooling) Fan control (Normal cooling)
Four way valve OFF OFF OFF
Main electronic expansion valve
(EV1)
480 pls 480 pls 480 pls
Subcooling electronic expansion
valve (EV3)
SH control 0 pls 0 pls
Hot gas bypass valve (SVP) OFF OFF OFF
Ending conditions 20 sec.
• 3 min.
• Ts - Te<5°C
• 3 min.
• Pe<0.6MPa
• HTdi>110°C
or
or
Indoor actuator Cooling oil return operation
Indoor unit fan
Thermostat ON unit Set Air Volume
Stopping unit OFF
Thermostat OFF unit Set Air Volume
BP unit electronic expansion
valve
Thermostat ON unit SH control
Stopping unit 77 pls
Thermostat OFF unit SH control
