English 4 To remove the drill bit taper shank insert the cotter into the slot of the taper shank adapter and strike the head of the cotter with a manual hammer supporting on a rest Fig 13 USING DRILL CHUCK CHUCK ADAPTER Note that this machine can be used at rotation only if separately sold parts such as drill chuck and chuck adapter are attached Use it with the selector lever positioned at rotation hammering CAUTION During operation be sure to grip the handle and the side handle firmly to prevent your body from swaying 1 Switching to rotation hammering For switching to rotation hammering follow the same procedures mentioned in 3 When drilling at rotation hammering 2 Attaching chuck adapter to drill chuck Fig 14 a Attach the chuck adapter to the drill chuck b The SDS max shank of the chuck adapter is equivalent to the drill bit Therefore follow the same procedure as How to install tool for attaching and detaching 3 Drilling a Even if you apply more than required pressure to the machine body drilling can never be performed as quickly as you expect Applying more force or pressure to the machine body than what is needed on the contrary damages the drill tip resulting in the declined working efficiency and shortened life of this machine b A drill can snap sometimes when drilling is almost finished It is important to relax your thrusting pressure when drilling is nearing the end HOW TO HANDLE A CORE BIT When a core bit is used large diameter holes and blind holes can be drilled In this case use optional accessories for core bits such as a center pin and core bit shank for more efficient operation 1 Mounting CAUTION Prior to mounting a core bit always disconnect the plug from the power supply receptacle 1 Mount the core bit on the core bit shank Fig 15 Before that feed oil to the screw portion of core bit shank for easy dismounting 2 Mount the core bit shank on the main body in the same manner as in mounting the drill bit and the bull point Fig 16 3 Insert the center pin into the guide plate until it reaches the extremity 4 Fit in the guide plate by aligning its concaved portion with the core bit tip When the position of the concave is shifted by turning the guide plate right or left the guide plate never slips off even when the drill is used in a downward direction Fig 17 2 Drilling holes 1 Insert the plug into a receptacle 2 A spring is built in the center pin By straightly and gently pressing it to the wall or floor surface the entire surface of the core bit tip attains contact to start the hole drilling job Fig 18 3 When the hole depth reaches approximately 5 mm the hole position can be determined Then remove the center pin and guide plate from the core bit and continue the hole drilling job CAUTION When removing the center pin and guide plate always disconnect the plug from the receptacle 3 How to dismount the core bit O By holding the rotary hammer with the core bit inserted in an upward position drive the rotary hammer to repeat impact operation two or three times whereby the screw is loosened and the rotary hammer becomes ready for disassembly Fig 19 O Remove the core bit shank from the rotary hammer hold the core bit with one hand and strongly strike the head of the SDS max shank portion of the core bit shank with a manual hammer two or three times whereby the round head screw is loosened and the rotary hammer is ready for disassembly Fig 20 HOW TO REPLACE GREASE This machine is of full air tight construction to protect against dust and to prevent lubricant leakage Therefore the machine can be used without lubrication for long periods Replace the grease as described below 1 Grease replacement period After purchase replace grease after every 6 months of usage Ask for grease replacement at the nearest Hitachi Authorized Service Center Proceed for replacement of grease 2 Grease replenishment CAUTION Before replenishing the grease turn the power off and pull out the power plug 1 Remove the crank cover and wipe off the grease inside Fig 21 2 Supply 60 g of Hitachi Electric Hammer Grease A Standard accessory contained in tube to the crank case 3 After replenishing the grease install the crank cover securely NOTE The Hitachi Electric Hammer Grease A is of the low viscosity type If necessary purchase from an Hitachi Authorized Service Center MAINTENANCE AND INSPECTION 1 Inspecting the tool Since use of a dull tool will degrade efficiency and cause possible motor malfunction sharpen or replace the tool as soon as abrasion is noted 2 Inspecting the mounting screws Regularly inspect all mounting screws and ensure that they are properly tightened Should any of the screws be loose retighten them immediately Failure to do so could result in serious hazard 10
