Provide enough space for good air flow and ensure the following minimum distances are observed
around the sides of the Box PC.
• Book Mount
Z
X X
Y
Y
• Wall Mount in landscape
A
or portrait
B
orientation
X X
X X
Y
Y
Y
Y
A
B
B+A
Z
Item
Minimum distance
*1
X 50 mm
Y 100 mm
Z 50 mm
*1. Measure the minimum distances X and Y at the air openings in the sides of the Box PC.
Check the required bending radius of all wires for the actual required minimum distance.
5 Installation
5-18
NY-series Industrial Box PC Hardware User's Manual (W553)
